FEATURES
1. The sensor is of hard alloy bearing thrust type, which may guarantee the precision and improve the wear resistance performance as well.
2. Simple and firm structure, easy for installation and dismantling.
3. Wide range of measuring and extremely low flow rate lower limit.
4. Small loss of pressure, fine repeat ability and high precision.
5. High resistance to electromagnetic interference and vibration.
TECHNICAL PARAMETERS
| Power supply | 24VDC power suppy, current ≤10mA | |
| Power supply & Output | Transducer | Pulse/4-20mA output |
| Transmitter |
Pulse + 4-20mA output (Optional: RS485) |
|
| Medium temperature | -20～＋100℃ | |
| Ambient temperature | -20～＋50℃ | |
|
Flow range of different pipe size |
4mm | 0.04-0.25m³/h |
| 6mm | 0.1-0.6m³/h | |
| 10mm | 0.2-1.2m³/h | |
| 12mm | 0.4-2m³/h | |
| 15mm | 0.6-3.6m³/h | |
| 20mm | 0.7-7m³/h | |
| 25mm | 1-10m³/h | |
| 32mm | 1.5-15m³/h | |
| 40mm | 2-20m³/h | |
| 50mm | 4-40m³/h | |
| 65mm | 7-70m³/h | |
| 80mm | 10-100m³/h | |
| 100mm | 20-200m³/h | |
| 125mm | 25-250m³/h | |
| 150mm | 30-300m³/h | |
| 200mm | 80-800m³/h | |
| Connection method | Thread/Flange/Clamp connection | |
| Transducer material | SS304 (Optional: SS316) | |
