Items
|
Parameters
|
|
Executive standard
|
ISO4064-2014、GBT778-2018
|
|
Measurable fluid
|
Water, sewage, seawater (other liquid need be customized)，Liquid full of pipeline
|
|
Fluid temperature
|
0.1-30℃
|
|
Work environment
|
temperature: -30-45℃； humidity:100%( RH )
|
|
Bearable pressure
|
1.6MPa, 2.5MPa alternatives
|
|
Pressure loss
|
DN15-DN40 △P40;≥DN50 △P10
|
|
The sensitivity grade of upstream
|
U3
|
|
The sensitivity grade of downstream
|
D0
|
|
Climate and mechanical environment
|
C class
|
|
Electromagnetism copatibility grade
|
E2 class
|
|
Communication interface
|
RS485/USART/infrared interface, M-BUS alternatives;NB-lot wireless transmission
|
|
Output signal
|
OCT alternatives
|
|
Power supply
|
2 built-in lithium batteries/external DC8-24V power supply
|
|
Protection grade
|
IP68
|
|
Spot display
|
Screen with two rows: 9digital accumulated flow display,6 digital instantaneous
flow display,various condition prompt symbols and units. |
|
Data storage
|
Ferroelectric storage parameters usage, recording accumulated flow of 32moths and 31days before automatically
|
|
Flow measurement cycle
|
Measurement condition: 1time/second(settable); Authentication condition: 4times/second
|
|
Power consumption
|
Standard condition < 30uA, working 20 years above constantly
|
|
Materials
|
Measuring pipe: carbon steel(stainless steel for sensor); sensor: PEEK; protection cover:nylon plus glass fiber
|
